• Issue receipts fast thanks to bi-directional printing.
• Gives 3.5 LPS for 40 columns or 6.4 LPS for 16 columns.
• Replace paper quickly and easily at paper end with the drop-in roll-paper loading system.
• For the broadest selection of applications, use the TM-U200 in combination with an EPSON intelligent Module. You can also choose the printer with 2-color printing (red and black) for further applications.
Print Method | 9-pin, Serial Impact Dot Matrix | |
Print Font | 7 X 9 / 9 X 9 | |
Column Capacity | 40 or 42 columns / 33 or 35 columns | |
Character Size | 1.24 (W) X 3.1 (H) mm / 1.56 (W) X 3.1 (H) mm | |
Character Set | 95 Alphanumeric Characters, 32 International Characters, 128 X 8 Graphic Characters | |
Print Speed | Approx. 3.5 LPS (40 columns, 16CPI) | |
Data Buffer | Serial I/F 1K bytes or 40 bytes / Parallel I/F 1K bytes or 0 bytes | |
Interface | RS-232C, Bi-directional Parallel, RS-485 (option) | |
Paper | 76 mm. +/- 0.5 mm. X max. dia. 83.0 mm. (roll) | |
Paper Thickness | 0.06 to 0.085 mm. | |
Copy Capacity | One Original and Two Copies | |
Power Supply | AC Adapter (included), PS-170 (option) | |
Power Consumption | Approx. 43 W average | |
D.K.D. Function | 2 Drivers | |
Overall Dimensions | 160 (W) X 248 (D) X 133 (H) mm | |
Weight | Approx. 2.2 kg. |
