Dillon Dynamometer Digital AP 5¨ 500 lb
Has a 5¨ diameter, whose housing is highly resistant plastic, ideal for operating in difficult environments, unlike the Dillon Dynamometer Digital AP 10¨ whose processing is made of aluminum. Dillon Dynamometer Digital AP 5¨ 500 lb. meets the tensile and weight determination function, which is enabled thanks to its stretching or elasticity system that includes a spiral-shaped springs arranged inside the Dillon Dynamometer Digital AP 5¨ 500 lb.
The operating mechanism of the Dillon Dynamometer Digital AP 5¨ 500 lb is carried out by two hooks one at each end, which allows that whenever an object is hung at the available end a force is exerted and a value is expressed Which can be read by means of the needle of this device.
This measuring device was designed with the purpose of measuring the voltage of the telephone cables, however the Dillon Dynamometer Digital AP 5¨ 500 lb can be used in several applications where it is necessary to quantify tension and weight, among them: ; Assembly of cables for bridges; Adjust cable tension, among other functions.
Dillon Dynamometer Digital AP 5¨ 500 lb
Is able to cover various functions either at the level of weight measurements of objects or to be useful in what physical tests are treated, since it is possible to perform tests of deformation and traction, this is Usually used in laboratories, high engineering constructions and damping tests. Another relevant use of the dynamometer is in the field of dentistry, in orthodontic treatment, to determine the application of force to be used in the same
The Dillon Dynamometer Digital AP 5¨ 500 lb is built with anti-corrosive protection, which is coated with anti-dust paint; The shackles and pegs are nickel plated; As well as all the internal components are made with anti-corrosive materials or if they have a cover that gives maximum protection or hermetic sealing.
SPECIFICATIONS of DILLON AP DINAMOMETERS:
Accuracy: |
+ 0.5% of capacity |
Temperature range: |
-50° to 140° F (-45° to 60° C) |
Ultimate Safety Factor: |
See table on cover for minimum USF |
Construction: |
Pressure bar -
Shackles -
Shackle pins - |
Case housing: |
5” models are equipped with high strength composite plastic case. 10” models use cast aluminum enclosure. |
Corrosion protection: |
Pressure bar protected with durable powder coat paint. Shackles and pins are electroless nickel plated. All integral machining and fasteners are produced from noncorrosive materials or have suitable plating. |
Zero control: |
Zero up to 20% of capacity. Zeroed load must be considered as part of ultimate load. |
Calibration: |
Traceable to NIST. |
Documentation: |
Includes User’s Guide and signed calibration card. |
Carry case/crate: |
Low/Med capacity 5" dial - includes plastic carry case |
Periodic proof loads: |
Controlled 150% proof loads permitted annually. |
